    New Original Huawei R4875G1 Rectifier Module

    Ask Lasest Price
    Brand Name : Huawei
    Model Number : R4875G1
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, Western Union, Paypal
    Supply Ability : 100 PCS / Month
    Delivery Time : 2-3 days
    • Product Details
    • Company Profile

    New Original Huawei R4875G1 Rectifier Module

    The Huawei R4875G1 Rectifier Module is a digital rectifier with high efficiency and high power density. lt supports a wide input voltage range and provides 53.5v DC default output voltage. R4875G1 Rectifier Module provides comprehensive protection functions and supports soft start with low noise. Multiple rectifiers can be connected inparallel. With the power monitoring technology, states of the rectifier and load are monitored in real time, and the output voltage can be adjusted.

    EfficiencyPeak efficiency: 97%>96% (230 V AC, 30%–80% load)
    Dimensions (H x W x D)40.8 mm x 105 mm x 269 mm
    Weight≤ 2.2 kg
    Cooling modeBuilt-in fan (fan speed adjustment)
    Environment Specifications
    Operating temperature–40°Cto +75°C
    Storage temperature–40°Cto +75°C
    Relative humidity5%–95% RH (non-condensing)
    Altitude≤ 5000 m (When the altitude ranges from 2000 m to 5000 m, the operating temperature decreases by 1°Cfor each additional 200 m.)
    Electrical Specifications
    Input
    Operating voltage range85 V AC–300 V AC
    Input frequency45 Hz–66 HzRated frequency: 50 Hz/60 Hz
    Rated input current≤ 21 A
    Power factor≥ 0.99 (50%–100% load)
    THD≤ 5% (50%–100% load)
    Output
    Output voltage42 V DC–58 V DCRated voltage: 53.5 V DC
    Output power4000 W(176 V AC–300 V AC)4000 W–1600 W (176 V AC–85 V AC)
    Peak efficiency97%±0.2%
